Racepak IQ3 Logger Dash

Need a display dash without the hassle of an external logger? The Racepak IQ3 Logger Dash delivers full data acquisition for road racing, marine, pulling, and more—no bulky hardware or messy harnesses. With V-Net sensor connectivity and up to 47 sensor channels, GPS speed/track mapping, and customizable alerts, our IQ3 Logger Dash gives you the competitive edge!

The IQ3 Logger Dash merges Racepak’s V-Net single cable sensor technology and proven GPS based data logging with a fully programmable display, creating a complete data center. The full feature dash includes an internal 42 sensor channel data logger, while track mapping and speed is obtained by the internal GPS board and 3 axis G meter thus eliminating the need for an external data logger, beacon receiver and wheel speed sensor. No sensor wiring harness is required, as all external sensor data is routed to the rear of the dash by a single V-Net cable. The DatalinkII software included with the IQ3 dash provides professional level data analysis capabilities, but in an easy to learn format.

Features:

• 47 Total Data Channels (42 V-Net digital/analog, 5 internal)
• Internal GPS board - GPS speed, lap time and track mapping
• 3-Axis G Meter (accel, lateral, vertical)
• Display up to 28 inputs via 4 pages
• 8GB microSD Memory Card included (Logger Dash capable of up to 16GB memory)
• User defined sensor input names
• User defined shift lights
• 8 User defined alarms/screen alerts
• Shielded low luster screen for sunlight viewing
• Blue backlit screen for night time viewing
• Metric and english capable
